Model No.： TGr-MFZL-*PE
Min. Order： 2000pcs
Trade Terms：FOB,CNF,CIF
Payment Terms ："T/T,L/C
Inquiry NowPortable ABC Dry Powder Fire Extinguisher
BS EN3-7 Approved
Products series specification
| TGr-MFZL1-PE | TGr-MFZL2-PE | TGr-MFZL6-PE | TGr-MFZL9-PE | |
| Cylinder size | D85XH285mm | D110XH315mm | D160XH445mm | D180XH490mm |
| Cylinder material | ST12 | |||
| Cylinder weight | >680g | >1150g | >2.7Kg | >3.2kg |
| Cylinder capacity | 1.30L | 2.60L | 7.80L | 11.8L |
| Working pressure | 14Bar | |||
| Test pressure | 29Bar | |||
| Safety valve operation pressure | 22Bar | |||
| Working temperature | -30oC~+60oC | |||
| Propellant gas | Nitrogen | |||
| Declare fire rate | 8A 34B C | 13A 55B C | 43A 233B C | 55A 233B C |
| Reference fire rate | 5A 21B C | 8A 34B C | 27A 144B C 34A 183B C | 34A 183B C 43A 183B C |
| Fire Extinguisher Mesa | D85XH340mm | D110XH400mm | D160XH550mm | D180XH600mm |
| Product weight | 2000g+20g | 3.5kg+50g | 9.3Kg+100g | 13.2kg+0.2kg |
| Inner Package size | L9XW9XH35cm | L12XW10XH41cm | L17XW17XH55cm | L20XW19XH62cm |
| Master cartpn size | 45X19X36cm/10pcs | 24X23X42cm/4pcs | 17X17X55cm/1pc | 20X19X62cm/1pc |
| Fire Extinguisher agent | EN 615 40% ABC dry chemical powder | |||
| 1000g+20g | 2000g+40g | 6kg+120g | 9.0kg+150g | |
Notice:
* This products is BS EN3-7 approved fire extinguisher. The OEM service is valid, but the parts can't change!
* The products must under periodically check. If the product gauge pointer is not in the gree zone, the fire extinguisher need send to profisional maintenance immediately!
* The Fire Extinguisher is not a toy, please keep away from kid without training!
* Products warranty is 4years, please send to profisional maintenance in time before the expriy. The manufacture time show on the products body stamp.
