Model No.： TGr-EL-D
Min. Order： 200sets
Trade Terms：FOB, CNF, CIF
Payment Terms ："TT, LC
Inquiry NowFire Escape Ladder
EL D Series:
Products series: EL45D (4.5m length, for 2 floor buliding)
EL75D (7.5m length, for 3 floor buliding)
EL1055D (4.5m length, for 4 floor buliding)
Loading capacity: Statics situation 350kgs
Dynamic situation 200kgs
Product weight: EL45D- 5.40kg
EL75D- 8.5kg
EL105D-11.4kg
Antislip design valid.
Product satisfied the: ASTM 2175 (UL); BGI638 (the original one ZH1/368) (TUV)
| Items | TGr-EL45D | TGr-EL75D | TGr-EL105D |
| Ladder length | 4.5M | 7.5M | 10.5M |
| Crossbar width | 310MM | 310MM | 310MM |
| Maximun loading rate of crossbar | 200KG | 200KG | 200KG |
| Maximun loading rate of ladder | 350KG | 350KG | 350KG |
| Warranty | 4Year | 4Year | 4Year |
| Packing size | 40X35X13cm | 40X35X26cm | 40X35X38cm |
Portable color box valid for MOQ 500pcs.
Notice!
* Fire ladder must be kept dry and well visible and marked by an escape route.
* Fire ladder should not be stored outdoors or in damp enviroument.
* Fire ladder must alwasys be ready to use, clearly visible and marked. Fire ladder should not used for other purposes.
* Everyone in the household should practice in the use of fire ladder.
* Fire ladder that is defective or damaged shoul not to be used.
