Fire Escape Ladder
EL BA Series:
Products series: EL45BA (4.5m length, for 2 floor buliding)
EL75BA (7.5m length, for 3 floor buliding)
Loading capacity: Statics situation 350kgs
Dynamic situation 200kgs
Product weight: EL45BA- 6.0kg
EL75BA- 8.5kg
Antislip design valid. Lightly desin for the EL B Series.
Product satisfied the: ASTM 2175 (UL); BGI638 (the original one ZH1/368) (TUV)
| Items | TGr-EL45BA | TGr-EL75BA |
| Ladder length | 4.5M | 7.5M |
| Crossbar width | 310MM | 310MM |
| Maximun loading rate of crossbar | 200KG | 200KG |
| Maximun loading rate of ladder | 350KG | 350KG |
| Warranty | 4Year | 4Year |
| Packing size | 36X33X12cm | 36X33X23cm |
Portable color box valid for MOQ 500pcs.
Notice!
* Fire ladder must be kept dry and well visible and marked by an escape route.
* Fire ladder should not be stored outdoors or in damp enviroument.
* Fire ladder must alwasys be ready to use, clearly visible and marked. Fire ladder should not used for other purposes.
* Everyone in the household should practice in the use of fire ladder.
* Fire ladder that is defective or damaged shoul not to be used.
